Price: US$ 2,820
We have priced this in US$ in order to provide the best value for money by not having to price in a currency fluctuation buffer. We can accept payment in (British Pounds/ Australian Dollars/ New Zealand Dollars) at prevailing rates.
The Electronic Reflectorless Total Station ZTS-120R is a 2-Second Accuracy Reflectorless Total Station.
NZ-lasertools.com introduces ZTS-120R Series Electronic Reflectorless Total Station which offers high-end features in a reliable and affordable instrument. The ZTS-120R model is easy to use and is ideal for modern surveying, construction staking, mapping and GIS, geomarking, environmental studies as well as industrial applications.
The Total Station provides precise measurement up to 7500m with a single prism and 350m without a prism. The 30x powered instrument has a field of view of 1°30' with a minimum focus of 1.5m. Data input is convenient too with this reflectorless total station. A dual-sided, LCD display is easy to read. The alpha/numeric keyboard is easy to use and program. Offering improved productivity, the ZTS-120R features powerful on-board software in addition to the freedom of prism-less measurement.
Transfering measurements is simple with the versatility of data transfer the ZTS-120R provides. Data can easily be downloaded from the instrument to a computer through a USB port/RS-232 port. The ZTS-120R Series Reflectorless Total Station features a water-resistant (to the recognized standard IP54) housing and is powered by an on-board battery. All the components that accompany the instrument fit into a rugged carrying case.
2-Second accuracy
Working range up to 7500m with single prism
350m working range without prism
Superior Optics (30x Magnification)
Water-resistant housing to IP54 specification
Easy to target collimator
Storage of up to 20,000 points
USB and RS-232 interface
Easy to target collimator
Long dual-sided graphic display and alpha/numeric keyboard
Data upload and data transfer through RS-232 data or USB port
Alpha / Numeric keypad
Surveying and Construction
Mapping and GIS
Utilities
Environment Studies
Geomarking
Archaeology
Accident Reconstruction
Total Station Instrument, Battery Pack, Battery Charger, Laser plumb-bob, Set of Tools, Carrying Case, Software and Cable and Instruction Manual.
One year manufacturer's limited warranty.
NTS02 Manual English - a 1.6 MB PDF file. Click on the link to open the PDF manual in a new browser window or right-click on the link to save the PDF file to your hard drive.
